Jabsco # 18655-0001 Bronze Self-Priming Pump 1/6 HP

Jabsco Pump 18655-0001

Jabsco # 18655-0001

Jabsco catalog # 18655-0001, Bronze Self-Priming Pump and Motor unit. Bronze Construction, with a Neoprene Impeller and Lip Type Seal. Pump is Close Coupled to a 1/6 Horsepower, ODP (Open Drip Proof) Motor. Ports are 3/8 Inch NPT Female.

Price : Contact Us

Qty :

2 Weeks (0 in stock)

Click Here for PARTS



Product Information :

The Jabsco 18655-0001 is a bronze Flexible Impeller pump with a Neoprene Impeller, Lip Type seal, 3/8 Inch NPT Female Ports, coupled to a 1/6 Horsepower, ODP, 60 HZ Motor, with a 8' Cord 3 Prong Grounded Plug. LIQUID TEMPERATURE RANGE: Neoprene Impeller: 45 degrees to 180 degrees F ( 7 degrees to 82 degrees C) . For general transfer pumping where self-priming, 3 gpm flow, debris tolerance and portable 115 VAC operation is desired.

Do not run dry. Impeller Depends on liquid pumped for lubrication. Dry Running will damage the impeller.

Features :

Pump Body:
Bronze
Impeller:
Neoprene
Shaft Seal:
Lip Type
Port Size:
Ports are 3/8 Inch NPT Female
Motor Specs :
1/6 Horsepower, ODP (Open Drip Proof).

Product Specs :

Easy to service and maintain.

Will tolerate abrasive wear .

Handles hard and soft solids without clogging.

Non pulsating flow


Parts and Accessories for Jabsco model 18655-0001


Shaft Seal :

Catalog # 18753-0384, Service Kit, Nitrile, with Impeller, O-Ring and Seal

Price: $ 36.52

Qty :

Can Ship : Same Day (2 in stock)

Applications

Widely used in Metalworking Factories, Agriculture and Horticulture, Waste and Water Treatment works, Many areas of manufacturing and production, Plumbing and home maintenance services Especially suited to Sumpemptying and cellar drainage, Machine tool coolant transfer, Cleaning and filtration, Washdown equipment, Transfer and recirculation. Other applications include INDUSTRIAL Circulating, transferring, velocitymixing, pumping machine tool coolants, sump drainage, soap, ink, dyes, alcohol, glycerine, brine and heliarc welding equipment cooling. FARMING Livestock watering, pumping water from shallow wells and cisterns. MARINE Washdown and utility dock side pumping. PLUMBING and HOME EMERGENCY USE Pumping out flooded basements, cesspools, sumps, water heaters and water closets, drains and sinks, draining fishponds and small pools. PUBLIC UTILITIES AND MUNICIPALITIES Dewatering and draining meter boxes and excavations, dust control and sampling.Flow rate Nominal 2.8 US gallons/min 10.6 Litres/min.
