Oberdorfer Pump # 50P-15 Parts Order page( Click Here for the Oberdorfer Pump # 50P-15 Product Page ) |
|
Parts Table is below the image. Scroll down for Item Listings and Prices. Products in the table are matched to the number on the image using a Item Key. |
| Parts List for Oberdorfer Pump model # 50P-15 | |||||||
| Key | Part # | Description | Price | Stock | Required | Quantity | Action |
|---|---|---|---|---|---|---|---|
| KIT | # 10690 | Repair Kit - includes Gasket, Impeller, Seal Assembly, Shaft and Bearing, Shim | $322.00 | 6 in Stock | 1 | ||
| 1 | # 5385 | Screw | $4.72 | 34 in Stock | 6 | ||
| 2 | # 6483 | Cover | $194.00 | 2 in Stock | 1 | ||
| 3 | # 6502 | Gasket | $7.88 | 4 in Stock | 1 | ||
| 4 | # 6476 | Impeller | $142.00 | 2 in Stock | 1 | ||
| 5 | # 32154 | Seal Assembly | $89.30 | 2 in Stock | 1 | ||
| 6 | # 6052 | Plug | $14.03 | 0 in Stock | 1 | ||
| 9 | # 5595 | Screw | $7.88 | 0 in Stock | 1 | ||
| 10 | # 5741 | Retaining Ring | $7.88 | 2 in Stock | 1 | ||
| 11 | # 5348 | Shaft and Bearing | $266.00 | 40 in Stock | 1 | ||
| 12 | # 6484 | Pedestal | $270.89 | 3 in Stock | 1 | ||
| 13 | # 7736 | Tag | $29.15 | 0 in Stock | 1 | ||
| 14 | # 602502 | Shim | $12.29 | 0 in Stock | 1 | ||
