Weinman # 2L4A Split Case Pump

Weinman Pump 2L4A

Weinman # 2L4A

Weinman catalog # 2L4A, Horizontal Single Stage Split Case Pump end only, no motor, Cast Iron construction, Bronze impeller, Buna/Carbon/Ceramic Mechanical seal. Inlet Port is 3 inch Inlet, Discharge Port is 2 inch Discharge.

Price : $ 8753.30

Qty :

6 Weeks (out of stock)



Product Information :

The Weinman 2L4A is a Cast Iron Horizontal Single Stage Split Case Pump end only, no motor, with Bronze Impeller, Buna/Carbon/Ceramic Mechanical Seal, 3 inch inlet by 2 inch Discharge Ports, replacement pump end only without a Motor. This split case pump meets a wide variety of service needs and provides large capacity general service pumping. Rugged and reliable, it combines mechanical simplicity with sophisticated hydraulic design. Recognized for their quality, efficiency and economy, Weinman split case pumps meet the design criteria of: ASTM; HI; ANSI; AISI; SAE; and ASME. This Weinman L Series horizontally mounted pump provides higher efficiency, longer pump life and lower cost than comparable pumps. Extra heavy castings absorb vibration and hydraulic noise thereby assuring smooth and quiet operation. Standard pumps are bronze fitted with iron cases. Optional ductile versions are available. This pump features, as standard, a V trough base design that collects water from condensation and packing drippage. A connection for drain to waste is provided.
WEIGHT : The Weinman 2L4A weighs 270 Lbs.

Features :

Pump Body:
Cast Iron
Impeller:
Bronze
Shaft Seal:
Buna/Carbon/Ceramic Mechanical seal
Port Size:
Inlet Port is 3 inch Inlet, Discharge Port is 2 inch Discharge.
Motor Specs :
Horsepower.

Applications

There are many applications that the Weinman 2L4A are used in. Weinman SingleStage Split Case Pumps are recommended for large capacity municipal, commercial and general industrial liquid handling applications. Typical applications are Hot or chilled water circulation, Pressure boosting, Cooling tower, Potable water transmission and treatment, Boiler feed services requiring high pressure and volume, as well as General service pumping.
