MP # 50641 Chemflo 6 Close Coupled Pump and Honda 9 HP Engine HP

MP Pump 50641

MP # 50641

MP catalog # 50641, Chemflo 6 series Close Coupled Centrifugal Chemical Pump and Honda 9 HP Engine (Engine Drive), Stainless Steel construction, 4.7 inch diameter impeller, Teflon/Carbon/Ceramic T-9 Mechanical seal Mechanical seal for chemical duty. Inlet Port is 3 inch, Discharge Port is 2 inch 150 lb. ANSI flange.

Price : $ 5472.33

Qty :

2 Weeks (0 in stock)



Product Information :

The MP 50641 is a Stainless Steel Chemflo 6 series Close Coupled Centrifugal Chemical Pump and Honda 9 HP Engine (Engine Drive), with 4.7 inch Diameter Impeller, Teflon/Carbon/Ceramic T/9 for chemical duty Mechanical Seal, 3 inch by 2 inch 150 lb. ANSI flange Ports, close coupled to a Horsepower Motor. Motors for this chemical pump include the 145TC, 184TC, and 215TC. The CHEMFLO 6 CC uses stainless steel parts to keep your pump running healthy and efficiently, ensuring no internal corrosion results. The end suction pump comes standard with a wide variety of mechanical seals to suit any application. The ChemFlo 6 pumps utilize an enclosed impeller designed for achieving higher heads and efficiencies than a standard semi-open impeller. Multiple impeller trims allow the ChemFlo 6 to meet most duty points up to 450 GPM and total head up to 157 feet. Several mechanical seal options are available in addition to the standard type 2100 carbon / ceramic / Viton mechanical seal. ChemFlo 6 pumps are offered in two configurations, pump (with motor) and PumPAK (without motor) versions. Motors available are 145TC, 184TC, and 215TC. If ordering a PumPAK please note that the electric motor must have a base.

Features :

Pump Body:
Stainless Steel
Impeller:
4.7 inch Diameter
Shaft Seal:
Teflon/Carbon/Ceramic T-9 Mechanical seal Mechanical seal for chemical duty
Port Size:
Inlet Port is 3 inch, Discharge Port is 2 inch 150 lb. ANSI flange.
Motor Specs :
Horsepower.

Applications

Typical applications for the Gardner Denver MP model 50641 are Agricultural, Commercial, Industrial, Marine, OEM.
