MP # 50306 Flomax 30 Pedestal pump end only

MP Pump 50306

MP # 50306

MP catalog # 50306, Flomax 30 series Pedestal Self Priming Centrifugal Pump end only, bare shafted, Stainless Steel construction, 6.75 inch diameter impeller. Inlet Port is 3 inch NPT Inlet, Discharge Port is 3 inch NPT 150 lb. Class Flat Flange Outlet.

Price : $ 6206.24

Qty :

2 Weeks (0 in stock)



Product Information :

The MP 50306 is a Stainless Steel Flomax 30 series Pedestal Self Priming Centrifugal Pump end only, bare shafted, with 6.75 inch Diameter Impeller, 3 inch NPT inlet by 3 inch NPT 150 lb. Class Flat Flange outlet Ports, replacement pump end only without a Motor. The 316 Stainless Steel FLOMAX 30 self priming centrifugal pump provides excellent chemical compatibility and corrosion resistance for "hard-to-handle" aggressive fluids making it ideal for numerous agricultural, industrial and marine applications. The self priming pump is equipped with a standard Viton flapper, priming chamber fill-plug, and a 3" NPT suction flange. Two basic pumpak styles allow the FLOMAX 30 self-priming centrifugal pump to fit standard Nema "C" electric motor frames, engines or the standard MP pedestal. The PUMPAK is completely assembled and can be mounted to a standard motor in minutes. Applications include: AG Fertilizer transfer, Chemical transfer, Diesel Exhaust Fluid (DEF) transfer and R.O. water transfer.

Features :

Pump Body:
Stainless Steel
Impeller:
6.75 inch Diameter
Port Size:
Inlet Port is 3 inch NPT Inlet, Discharge Port is 3 inch NPT 150 lb. Class Flat Flange Outlet.
Motor Specs :
Horsepower.

Applications

Typical applications for the Gardner Denver MP model 50306 are Agricultural, Industrial, Marine.
