MP # 36773 HTO 80 Pump Pack pump end only

MP Pump 36773

MP # 36773

MP catalog # 36773, HTO 80 series Hot Oil Centrifugal Pump Pack pump end only for mounting on a motor, with foot adapter for footless motor, Ductile Iron construction, 5.9 inch diameter impeller. Inlet Port is 1-1/2 inch, Discharge Port is 1-1/4 inch NPT or flat flange option.

Price : $ 2391.33

Qty :

Same Day (1 in stock)



Product Information :

The MP 36773 is a Ductile Iron HTO 80 series Hot Oil Centrifugal Pump Pack pump end only for mounting on a motor, with Foot adapter for footless motor, 5.9 inch Diameter Impeller, 1-1/2 inch by 1-1/4 inch NPT or flat flange option Ports, replacement pump end only without a Motor. The HTO 80 is an end suction centrifugal pump that is close coupled to standard NEMA "C" face motors. All models of these hot oil pumps are available in cast iron, bronze, or aluminum construction to suit a wide variety of liquids. Outfitted with an insulated air cooled seal chamber, this centrifugal pump was engineered to run efficiently at exceptionally high temperatures.

Features :

Pump Body:
Ductile Iron
Impeller:
5.9 inch Diameter
Port Size:
Inlet Port is 1-1/2 inch, Discharge Port is 1-1/4 inch NPT or flat flange option.
Motor Specs :
Horsepower.

Applications

Typical applications for the Gardner Denver MP model 36773 are Industrial, OEM.
