MP # 35516 Flomax 5 Pump and Motor unit 1 HP

MP Pump 35516

MP # 35516

MP catalog # 35516, Flomax 5 series Self Priming Centrifugal Pump and Motor unit, Cast Iron construction, 4.1 inch diameter impeller, T-21 Mechanical seal with a single convolution. Motor is 1 Horsepower, 115/230 Volts, Single Phase. Inlet Port is 1-1/2 inch, Discharge Port is 1-1/2 inch.

Price : $ 1683.49

Qty :

Same Day (1 in stock)



Product Information :

The MP 35516 is a Cast Iron Flomax 5 series Self Priming Centrifugal Pump and Motor unit, with 4.1 inch Diameter Impeller, T/21, a single convolution Mechanical Seal, 1-1/2 inch by 1-1/2 inch Ports, close coupled to a 1 Horsepower, 115/230 Volts, single phase Motor. Readily available in aluminum, cast iron, or bronze, the FLOMAX 5 self priming pump is capable of pumping highly toxic materials efficiently. This self priming centrifugal pump is utilized across the industrial, OEM, marine, and agricultural industries. 56C/145TC motors and gas engines can be close coupled to this centrifugal pump. A FLOMAX PumPAK is a fully assembled and run tested pump end that can be easily coupled to a number of drivers such as hydraulic motors, 56C and 145TC frame motors and gas engines. A bearing pedestal is also available for T-frame motor or belt drive. Standard features include stainless steel drive sleeve, stainless steel fasteners, renewable wear plate, and a semi-open dynamically balanced impeller. The FLOMAX series of pumps are commonly used in Industrial, OEM, Agricultural and Marine applications, such as: Bilge Pumps, Auxiliary Fire Pumps, Ballast Transfer Pumps, Washdown Pumps, Fertilizer and Pesticide Pumps, Applicators and Sprayers, Blending Pumps, Nurse Tanks, Bulk Transfer Pumps and much more.

Features :

Pump Body:
Cast Iron
Impeller:
4.1 inch Diameter
Shaft Seal:
T-21 Mechanical seal with a single convolution
Port Size:
Inlet Port is 1-1/2 inch, Discharge Port is 1-1/2 inch.
Motor Specs :
1 Horsepower, 115/230 Volts, Single Phase.

Applications

Typical applications for the Gardner Denver MP model 35516 are Agricultural, Industrial, Marine, OEM.
