Groco # ASA-500 1/2" Strainer with Monel Basket
Groco # ASA-500
Groco catalog # ASA-500, SA Series 1/2 Inch Raw Water Strainer with Monel Basket, Stainless Steel Enclosure, Bronze construction. Inlet Port is 1/2 Inch, Discharge Port is 1/2 Inch.
Price : $ 398.95
Product Information :
Parts Page (click here)
The Groco ASA-500 is a Bronze SA Series 1/2 Inch Raw Water Strainer with Monel Basket, Stainless Steel Enclosure, and 1/2 Inch by 1/2 Inch Ports. The MODELMODEL raw water strainer is the ideal filtration solution for cooling water intakes for any marine engine, air conditioning unit, or genset. This strainer is to be installed on the suction side of engines and pumps. The superior design makes them long lasting and easy to service while the variety of sizes means there is a fit for every application. In production for more than 50 years ASA series strainers are designed with a #316 stainless steel enclosure in place of a sight glass, and C84400 bronze head castings.
WEIGHT : The Groco ASA-500 weighs 5.6 Lbs.
Features :
Applications
Install SA series strainers vertically oriented above the outside waterline if possible. As with any plumbing system, the components will function with greater efficiency when restrictions are kept to a minimum. When planning the plumbing for SA Series Strainers assure that 90degree bends are utilized only when necessary and that hoses and fittings have as large and ID as possible. Use Groco full flow fittings if you can. Double clamp all hose connections and use TFE thread tape on threaded connections. Install SA series strainers in a location that allows for filter basket service. Use brackets on the valve body and on the end caps to mount to a sturdy bulkhead or stringer. Observe Inlet and Outlet markings on the strainer head. Ports are threaded for NPT connections.
